MultipleJs An Idea To Create Eye Catching Dashboards

Posted By : Sachin Arora | 24-Apr-2018

Multiple.js provides us a way to accomplish "background sharing effect across multiple elements" at HTML/CSS level without any co-ordinates processing by javascript.This effect provides us a creative way to present our dashboards just by using .



Quickstart



bower i multiple.js
npm i multiple.js


Including it on our page


<link href="./multiple.css" rel="stylesheet">
<script src="./multiple.min.js"></script>

How To Use

<!--HTML-->
<div class="item">Content</div>
<div class="item">Content</div>
<div class="item">Content</div>
// JavaScript
var multiple = new Multiple({
  selector: '.item',
  background: 'linear-gradient(#273463, #8B4256)'
});


Now The CSS Part

The idea  is just to get a background to be exactly the viewport's size and to be
displayedapprpriatly in every element chunk, to achieve it we need to use the property background-attachment: fixed


.selector {
  background-image: linear-gradient(white, black);
  background-size: cover;
  background-position: center;
  background-attachment: fixed;  /* <- here it is */

  width: 100px;
  height: 100px;
}

Now the background has been successfully expanded to full viewport's size, but what we want is to show a specific chunk of background under .selector element. so for that the background outside our .selector element needs to be cropped, providing the property overflow: hidden to our selector won't help as it's descendant is position: fixed. So to achieve that we need to use

 clip: rect(  property. The rule to use this clip property is that its parent must have position: absolute or fixed otherwise it won't crop.



.selector {
  position: absolute;
  clip: rect(0, auto, auto, 0);

  width: 100px;
  height: 100px;
}


Multiple.js plugin takes care of all the markup differences, vendor-prefixes, browser-specific workarounds etc.. for us. All we need is to specify the selector and background.
It also provides two methods .update() and .destroy()
  • update() - It is basically used to update the baackground image if you have passed it in params and also processes newly added tags.eg: .update('url(image.png)');

  • destroy() -  this destroy method is used to revert the layout to the original state if it was modified, also removes classes and destroys multiple instances.
