Configuring SSL in Apache Tomcat

In one of my project , I have done Tomcat SSL Configuration . In this blog I will share steps I followed to do the Tomcat SSL configuration.

• Create a directory in home directory

mkdir sslcertificate

cd sslcertificate

• Now second step is to generate keystore file

execute following command to generate .csr file

$JAVA_HOME/bin/keytool -genkey -alias {alias-name} -keyalg RSA -keystore sslcertificatekey -keysize 2048

On executing above command on terminal . I will ask for several information. Oragnization Name , country code , province ,domain name and password. when it prompt for first name - enter your domain name

where sslcerificatekey is the name of keystore file . It will generate in {home directory}/sslcertificate. Make a backup copy of sslcertificatekey and keep the password and safe as it will be needed to configure actual certificate.

• Now we need to generate .csr file . Run the below command in the console

$JAVA_HOME/bin/keytool -certreq -keyalg RSA -alias {alias-name} -file certreqssl.csr -keystore sslcertificatekey

where certreqssl.csr is .csr file will be generated in the directory where keystore file is generated.

• Use this csr file to get your certificate from a certificate authority.Make sure you download PKCS# 7 format i.e. .p7b file.
• Import your certificate using following command

$JAVA_HOME/bin/keytool -import -alias tomcat -keystore sslcertificatekey -trustcacerts -file www_mydomain_com.p7b -storepass {password}

if response is “Certificate reply was installed in keystore” then you have successfully import the certificate

• If there is any issue "“Failed to establish chain from reply” . follow the following steps
• Go to https://www.sslcertificaten.nl/download/Root_Certificaten/ and download the intermediate certificate provided by your certificate authority
• Execute the following command in console to import the primary and secondary certificate
• Use aliases primary and secondary while installing certificates as described below.

$JAVA_HOME/bin/keytool -import -alias primary -keystore sslcertificatekey -trustcacerts -file {primary-file name} -storepass {password}

$JAVA_HOME/bin/keytool -import -alias secondary -keystore sslcertificatekey -trustcacerts -file {secondary-file name} -storepass {password}

• Now made the following change in the {tomcat-home}/conf/server.xml
• Find the following connector configuration

<connector clientauth="false" maxthreads="150" port="8443" protocol="HTTP/1.1" scheme="https" secure="true" sslenabled="true" sslprotocol="TLS"> </connector>

add the following line

keystoreFile="{keystore path}" keystorePass="{keystore password}"

Your new connector will look like

<connector clientauth="false" keystorefile="{keystore path}" keystorepass="{keystore password}" maxthreads="150" port="8443" protocol="HTTP/1.1" scheme="https" secure="true" sslenabled="true" sslprotocol="TLS"> </connector>

that's it you are done with ssl configuration in tomcat

• now access https://:8443/ and accept the certificate
